Technical Specification
Electrical & Communication
| Item | Specification | |
| Power Supply | Input Voltage | DC 24 V: (Min: 21.6 VDC, Max: 26.4 VDC) |
| Communication Interface | RS-232 |
Performance Specification
| Cassette | Number of Cassettes | 1~3 |
| Cassette Capacity | 1750 ATM Fit USD Notes (9 13/16″, 250mm) | |
| Reject Tray Capacity | Single reject, at least 100 notes | |
| Low Currency | Cassette Low Level Sensor (Default 150 notes, 85-100 ATM fit notes) | |
| Security Feature | Mechanical key lock and plastic seal | |
| Media Specification | Note length | 110mm ~ 172mm |
| Note Width | 55mm ~ 85mm | |
| Note Thickness | 0.06mm ~ 0.18mm | |
| Note Feeding Method | Friction | |
| Note Dispensing Type | Single Dispensing | |
| Dispensing Speed | 7 notes/second | |
| Single maximum number of notes dispensed | 50 notes | |
| Dispenser Configuration | Front service | |
| Dispenser Weight | Dispenser weight with 1-cassette: 43 lbs. (19.5 kg). Dispenser weight with 2-cassettes: 64 lbs. (29.04 kg). Dispenser weight with 3-cassettes: 85 lbs. (38.56 kg). |
